HOME > PRODUCT > STARTER COMPONENTS
SD1410
Servicing MB301-18-400C
KIA PRIDE, MAGNET TYPE
SD1411
NO. OF TEETH : 9
PINION O.D. : 29.0 mm
BUSHING I.D. :
ROTATION : CW
NO. OF SPLINE : 10
LENGTH : 50.5 mm
CLUTCH O.D. : 47.6 mm
Replacing 1006 209 959
Servicing 0001108202
BOSCH
SD1412
NO. OF TEETH : 11
PINION O.D. : 34.6 mm
BUSHING I.D. :
ROTATION : CCW
NO. OF SPLINE : 10
LENGTH : 133.5 mm
CLUTCH O.D. : 546.0 mm
Servicing 0K60A-18-400
KIA BONGO
SD1413

NO. OF TEETH : 9

PINION O.D. : 35.0 mm

BUSHING I.D. :

ROTATION : CW

NO. OF SPLINE :

LENGTH : 100.0 mm

CLUTCH O.D. : 64.6 mm
Replacing 8941529750,
8943349760, 8943654800,
22402500, 22408500, 22409500

Servicing 8943205310,
8943334380, 8943654760,
S2403A. S2403B, S2403C,
S25161

SD1414
NO. OF TEETH : 13
PINION O.D. : 39.5 mm
BUSHING I.D. :
ROTATION : CW
NO. OF SPLINE : 19
LENGTH : 18.3 mm
CLUTCH O.D. :
Replacing M605X66071
Servicing 36100-42050, MG122433
HYUNDAI STAREX
SD1415
NO. OF TEETH : 13
PINION O.D. : 39.5 mm
BUSHING I.D. :
ROTATION : CW
NO. OF SPLINE : 10
LENGTH : 129.0 mm
CLUTCH O.D. : 68.0 mm
Servicing 36100-42050 M605X66071, MG122433
HYUNDAI STAREX
SD1416
NO. OF TEETH : 13
PINION O.D. : 39.5 mm
BUSHING I.D. :
ROTATION : CW
NO. OF SPLINE : 19
LENGTH : 18.2 mm
CLUTCH O.D. :
Servicing MG122202, HQ808670 BOXER
SD1417
NO. OF TEETH : 13
PINION O.D. : 39.5 mm
BUSHING I.D. :
ROTATION : CW
NO. OF SPLINE : 10
LENGTH : 130.5 mm
CLUTCH O.D. : 68.0 mm
Servicing MG122202, HQ808670 BOXER
SD1418
Servicing M0T45071, D7E16, D6RA57
MITSUBISHI
SD1419
NO. OF TEETH :
PINION O.D. :
BUSHING I.D. :
ROTATION :
NO. OF SPLINE :
LENGTH :
CLUTCH O.D. :
Serving D2848
SD1420
Serving SONATA GEAR SHAFT Cargo 139200

SD1421
Replacing Cargo 233642
SD1422
Servicing TOPIC 03111-5050 CW 14T, OD:44.50
SD1424
Replacing 233641, 028300-8011
11T, 10 Splines
SD1425
Replacing 1.01.0870.1  54-154 231968
Servicing For DELCO 41MT seriese DD starter
